Muffle Box Furnace
Muffle Box Furnace

Muffle Box Furnace

Price 300000 INR/ Piece

MOQ : 01 Piece

Muffle Box Furnace Specification

  • Application
  • Ash Content Determination, Material Testing, Ceramic Processing, Heat Treatment
  • Mounting Type
  • Bench Top
  • Specimen Size
  • Chamber: 9 x 4 x 4 (inches)
  • Interface Type
  • Manual control, Power Input Cable
  • Display Type
  • Digital LED Display
  • Measuring Range
  • Ambient to 1200°C
  • Humidity
  • Max. up to 60% RH (operating environment)
  • Automation Grade
  • Semi-Automatic
  • Resolution
  • 1°C
  • Hardness
  • High-grade Ceramic Fiber Insulation
  • Operating Voltage
  • 220V AC
  • Accuracy
  • ±1°C
  • Frequency
  • 50 Hz
  • Test Range
  • Room Temperature to 1200°C
  • Temperature
  • Ambient to 1200°C
  • Power Supply
  • 220V AC, 50 Hz, Single Phase
  • Features
  • High insulation, Fast heating, Low heat loss, Energy efficient, Compact design
  • Response Time
  • Rapid heating, approx. 20°C per minute
  • Equipment Type
  • Laboratory Muffle Box Furnace
  • Usage
  • Laboratory, Industrial, Research
  • Capacity
  • 5-6 Liter
  • Machine Weight
  • Approx. 45 kg
  • Control Mode
  • Digital PID Controller
  • Temperature Uniformity
  • ±5°C throughout the chamber
  • Door Type
  • Front opening, insulated door with safety switch
  • Chamber Volume
  • Approx. 5 liters
  • Heating Rate
  • 10-20°C/minute (average)
  • Ambient Conditions
  • Use in dry, well-ventilated area
  • Chamber Material
  • High-temperature ceramic
  • Max Working Temperature
  • 1200°C (continuous use), 1250°C (maximum limit)
  • Exterior Material
  • Powder-coated Mild Steel
  • Safety Features
  • Over-temperature protection, Door safety interlock, Fuse protection
  • Heating Element
  • Kanthal (A1) wire
  • Insulation Material
  • Ceramic fiber blanket and refractory bricks



About Muffle Box Furnace



Experience the marvelous precision of our Advanced Muffle Box Furnace, engineered for laboratories, research, and industrial environments. Highlighted by its high-temperature Kanthal (A1) heating element and an exquisite blend of ceramic fiber insulation, this unit features a powder-coated mild steel exterior for durability. Achieve unbeatable energy efficiency, rapid heating rates, and temperature uniformity within 5C. With unmatched safety-including door interlock, over-temperature, and fuse protection-this bench-top furnace offers the lowest price for such refined excellence. Ideal for ash determination, heat treatment, and ceramic processing.

Diverse Applications and Competitive Edge

The Muffle Box Furnace stands out for its versatility across ash content determination, ceramic processing, precise material testing, and heat treatment. Its semi-automatic, bench-top design ensures ease of use in laboratories and research facilities. The primary competitive advantages include rapid temperature response, superb insulation, energy efficiency, and uniform heating. This furnace meets the needs of professionals requiring reliable, high-performance thermal solutions in both industrial settings and R&D labs.


Sample Availability, Export Markets, and Certifications

Sample units of the Muffle Box Furnace are available, allowing you to assess product excellence before making an exchange at the asking price. The furnace is exported to major global markets, with strong distribution networks across Canada and beyond. Supported by transport services for safe delivery, it holds industry certifications, reinforcing its reliability and compliance with quality standards. Ask about export processes, available documentation, and current certification status for complete peace of mind.


FAQ's of Muffle Box Furnace:


Q: How does the Muffle Box Furnace ensure temperature uniformity throughout the chamber?

A: The furnace features advanced ceramic fiber insulation and a high-grade Kanthal (A1) heating element, maintaining a temperature uniformity of 5C. Its digital PID controller further ensures precise temperature regulation across the chamber.

Q: What safety features are included in this Muffle Box Furnace?

A: This model incorporates over-temperature protection, a door safety interlock, and fuse protection, ensuring safe operation and enhanced user security during high-temperature processes.

Q: When is it optimal to use this furnace, considering its working temperature range?

A: The furnace is ideal for processes requiring continuous operation at up to 1200C and short bursts to a maximum of 1250C. It is perfect for laboratories and industrial settings needing reliable, high-temperature processing.

Q: Where is the Muffle Box Furnace commonly used?

A: It is commonly used in laboratories, research centers, material testing facilities, and industrial environments that need precise heat treatment and ash content analysis.

Q: What are the main competitive benefits of this Muffle Box Furnace?

A: Key benefits include energy efficiency, fast heating (up to 20C per minute), compact design, and a digital LED display. These features provide unbeatable value and functionality for a wide range of thermal applications.

Q: Can samples be arranged and what are the transport provisions?

A: Yes, samples are available for evaluation. Transport services are arranged to ensure safe delivery, and export documentation is provided to comply with international regulations.
