Total Organic Carbon Analyser

Get a Price/Quote

MOQ : 1 Piece

Total Organic Carbon Analyser Specification

Specimen Size
Typical sample volume 20 ml (10-40 ml adjustable)

Gas Pressure
0.3-0.6 MPa

Automation Grade
Automatic, with optional Autosampler

Mounting Type
Benchtop

Interface Type
USB, RS232, LAN

Frequency
50/60 Hz

Response Time
2-5 minutes per sample

Power Supply
230 V AC, 50/60Hz

Temperature
Ambient: 5°C - 40°C

Display Type
7-inch Color Touchscreen LCD

Resolution
0.001 mg/L

Features
Automatic calibration, Data storage, NDIR detection, Auto diagnostic

Operating Voltage
230V AC

Port Size
Inlet 1/4

Test Range
0.001 - 10000 mg/L

Measuring Range
0.001 to 10000 mg/L TOC

Equipment Type
Total Organic Carbon Analyser

Humidity
20-80% RH (non-condensing)

Accuracy
± 2% FS

Application
Water, Wastewater, Environmental Monitoring, Pharmaceuticals, Industrial

Max Height
420 mm

Number of Specimens
1 (Single channel; multi-sample autosampler available)

Usage
Laboratory and Field Analysis

Capacity
Up to 100 samples with optional autosampler

Machine Weight
Approx. 12 kg

Test Speed
Programmable, typically 2-5 minutes per sample

Control Mode
Touchscreen Microprocessor Control

Alarm System
Audio/visual alerts for system errors or out-of-range values

Languages Supported
English, Chinese, user-selectable

Carrier Gas
High-purity oxygen or air, purity 99.99%

Calibration Interval
User-selectable, recommended monthly

Software Compatibility
PC connectivity for advanced data processing

Maintenance Interval
Monthly cleaning recommended

Memory Storage
Up to 10,000 results

Compliance
Conforms to USEPA and EN standards

Dimensions (W x D x H)
410 x 330 x 420 mm

Data Output
USB Export, Printer (optional)

Reagent Type
High-purity sodium persulfate or combustion method

Sample Introduction
Automatic syringe or manual injection

Enclosure Protection
IP21

Detection Principle
Non-Dispersive Infrared (NDIR)

Total Organic Carbon Analyser Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10 Pieces Per Week

Delivery Time
30 Days

Main Domestic Market
Karnataka, All India

Total Organic Carbon Analyser About

Under the exemplary leadership and guidance of our expert professionals, we have been able to emerge as a trusted supplier of Total Organic Carbon Analyser. This analyzer is designed to help in the management of water from public sources, wastewater and manufacturing processes. It is used to analyze organic and inorganic carbon in water, including the elemental carbon. The system utilizes combustion catalytic oxidation method to efficiently oxidize hard-to-decompose insoluble organic compounds. We offer this Total Organic Carbon Analyser at affordable prices to clients.

Features:

Automatic sample acidification and sparging
Wide measurement range
Automatic dilution function

Accurate and Rapid TOC Detection

The Total Organic Carbon Analyser ensures reliable and rapid measurement with its advanced NDIR detection principle, allowing for test speeds typically between 2 and 5 minutes per sample. This device is engineered to provide high accuracy (2% FS) and can accommodate a wide range of applications such as water quality monitoring, pharmaceutical analysis, and environmental assessments.

Flexible Operation and Data Handling

Equipped with both automatic and manual sample introduction modes, the analyser offers versatility to suit your workflow. Data management is enhanced by a substantial storage capacity for 10,000 results, an intuitive 7-inch touchscreen LCD, and multiple output options including USB, RS232, and LAN connectivity for seamless data export and advanced processing.

Safety and Compliance Built-in

The analyser features robust audio/visual alarms for system errors and out-of-range values, ensuring safe and consistent operation. Compliant with USEPA and EN standards, its IP21 enclosure provides essential protection, while monthly cleaning and calibration intervals contribute to maintenance simplicity and equipment longevity.

FAQs of Total Organic Carbon Analyser:

Q: How does the Total Organic Carbon Analyser detect organic carbon in samples?

A: The analyser uses a Non-Dispersive Infrared (NDIR) detection principle, which measures the concentration of carbon dioxide produced from the oxidation of organic carbon in the sample. This ensures precise quantification within a wide measuring range.

Q: What types of samples and industries can this analyser be used for?

A: This TOC analyser is ideal for laboratory and field analysis in water, wastewater, environmental monitoring, pharmaceutical, and various industrial applications requiring TOC measurement.

Q: When should I perform maintenance and calibration on the instrument?

A: Monthly cleaning and calibration are recommended to maintain optimal performance. The calibration interval is user-selectable, allowing adjustments based on usage frequency and application requirements.

Q: Where can stored data and results be exported from the device?

A: Results can be exported via USB, an optional printer, or through RS232/LAN connections to a PC for advanced data processing and archiving.

Q: How does the audio/visual alarm system enhance the devices usability?

A: The built-in audio and visual alerts notify users promptly about system errors or results outside preset ranges, ensuring quick interventions and uninterrupted operation.

Q: What are the benefits of the automatic autosampler option?

A: The optional autosampler increases sample throughput by allowing unattended analysis of up to 100 samples, making it beneficial for labs requiring high-volume or continuous testing.
