Surface Plasma Resonance SPRm 200S
Surface Plasma Resonance SPRm 200S

Surface Plasma Resonance SPRm 200S

Price 4500000 INR/ Piece

MOQ : 01 Piece

Surface Plasma Resonance SPRm 200S Specification

  • Number of Specimens
  • 1 (simultaneous multi-spot available)
  • Temperature
  • Ambient, with optional temperature control 1540C
  • Equipment Type
  • Surface Plasmon Resonance Microscopy (SPRm) System
  • Display Type
  • Color LCD Touch Panel, computer interface
  • Features
  • Real-time imaging, kinetic analysis, label-free quantification
  • Application
  • Biomolecular interaction analysis, label-free assay, kinetic study
  • Frequency
  • Image acquisition up to 2 Hz
  • Humidity
  • 20%80% RH (non-condensing)
  • Automation Grade
  • Semi-automatic
  • Response Time
  • Sub-second (software-dependent)
  • Interface Type
  • USB, Ethernet
  • Specimen Size
  • Coverslip / gold slide 24 x 24 mm
  • Max Height
  • 30 cm (approx unit height)
  • Power Supply
  • AC 100-240V, 50/60 Hz
  • Port Size
  • Microfluidic channel compatible (standard chip)
  • Operating Voltage
  • 100240V AC, 50/60 Hz
  • Mounting Type
  • Benchtop
  • Test Range
  • 10^-6 M to 10^-12 M (typical affinity)
  • Measuring Range
  • Up to 1,000 RU; kinetic rates 10^2 to 10^7 1/Ms
  • Accuracy
  • < 1 pg/mm (sensor chip) mass sensitivity
  • Resolution
  • Lateral: 1 m; Sensitivity 0.1 mDeg
  • Usage
  • Laboratory analytical measurement
  • Capacity
  • Single biosensor monitoring; multiplexed arrays possible
  • Machine Weight
  • Approx. 50 kg
  • Test Speed
  • Up to 2 Hz (image acquisition rate)
  • Test Width
  • Standard slide width (24 mm)
  • Test Stroke
  • Automated X-Y axis movement
  • Control Mode
  • Touch Screen / Computer Software
  • Detection Principle
  • Surface Plasmon Resonance Microscopy (SPRm)
  • Data Output Format
  • CSV, proprietary SPRm analysis
  • Software
  • SPRm acquisition and kinetic analysis suite
  • Chip Type
  • Disposable/reusable SPRm sensor chip
  • Compliance
  • CE, RoHS
  • Optical Resolution
  • Lateral spatial: 0.51 m
  • Sample Throughput
  • Depends on chip format; 18 spots
  • Sensor Surface Material
  • Gold-coated glass slide
  • Dimensions
  • Approx. 35 cm (W) x 40 cm (D) x 30 cm (H)
  • Light Source
  • LED or Laser (selected models)
  • Camera Type
  • High-sensitivity CMOS
  • Service Support
  • Onsite and remote support available
  • Flow Control
  • Optional, supports automated liquid handling



About Surface Plasma Resonance SPRm 200S

Surface Plasma Resonance

SPRm 200S

BIs SPR system is module-based, designed specifically for user flexibility and versatility. Our interchangeable analysis modules allow users to easily switch among fluid injection, electrochemical, and gas phase detection applications. detection applications.



High-Resolution Label-Free Analysis

Utilizing Surface Plasmon Resonance Microscopy, the SPRm 200S delivers high-resolution imaging down to 0.5-1 m. Its gold-coated sensor surfaces allow for sensitive detection of biomolecules without the need for labeling, facilitating detailed and reliable interaction studies.


Flexible Workflow and Throughput

The system supports both single and multiplexed sample analysis, offering throughput of 1-8 spots based on chip format. Its semi-automatic operation, touch screen control, and USB/Ethernet connectivity ensure ease of use and adaptability to varying laboratory demands.


Advanced Software and Real-Time Data

With a dedicated acquisition and kinetic analysis suite, the SPRm 200S provides immediate, sub-second response data. Outputs are available in CSV and proprietary formats for seamless integration with data workflows, and its interface supports both touch panel and computer control.

FAQ's of Surface Plasma Resonance SPRm 200S:


Q: How does the SPRm 200S detect biomolecular interactions?

A: The SPRm 200S uses Surface Plasmon Resonance Microscopy (SPRm), monitoring changes in light reflected off a gold-coated glass slide as molecules bind. This method enables real-time, label-free detection of molecular interactions.

Q: What sample throughput and chip types are supported by the SPRm 200S?

A: Sample throughput ranges from 1 to 8 spots depending on the SPRm sensor chip selected; both disposable and reusable gold-coated chips are compatible for flexible assay formats.

Q: When can real-time data be accessed during an experiment?

A: Real-time imaging and quantification are available throughout the assay, with a sub-second response time enabling immediate observation and kinetic analysis during sample measurement.

Q: Where are data outputs generated and how are they exported?

A: Data are generated via the integrated SPRm acquisition suite and exported in CSV or proprietary analysis formats, facilitating easy integration with laboratory data systems.

Q: What is the process for operating and controlling the SPRm 200S?

A: Operation can be managed via the color LCD touch panel or computer software. Automated X-Y axis movement and optional liquid handling streamline workflows, with simple control over assay parameters and data acquisition.

Q: How is onsite and remote service support provided for the SPRm 200S?

A: Service and support options include both onsite assistance and remote troubleshooting from trained technicians, ensuring the system maintains optimal performance and compliance.

Q: What benefits does the SPRm 200S offer for biomolecular research applications?

A: The system offers high mass sensitivity (<1 pg/mm2), precise lateral resolution (down to 0.5 m), real-time kinetic analysis, and label-free quantification, making it an indispensable tool for biomolecular interaction studies and laboratory assay development.
